Custom Aluminum and Stainless Steel Sheet Metal Stamping and Bending Fabrication for Polygonal Corner Fold Plates
-
Model NumberLZXMaterialsteel, stainless steel, aluminum, galvanized steel,
-
SizeCustomized sizeApplicationMachinery/Industry/Home/Automotive
-
ColorCustomized ColorProcessStamping
-
ServiceCustomized OEMUsagePrecision Metal Stamping Product
-
TypeOEM PartsEquipmentCNC Bending/Stamping Machine/Laser Marking
Polygonal plates with raised corner folds
The example plate has a polygonal outline, angled folds at its corners and a round opening near the center. These visible features distinguish it from a flat blank. Model LZX covers custom sheet metal processing, including stamping and bending work, with dimensions defined for the requested part.
Aluminum, stainless steel, steel and galvanized steel are named in the material information. The required grade and sheet thickness should accompany the drawing. Do not rely on the pictured surface to specify a metal or protective treatment.
Dimensions for the formed condition
Show the outer profile, opening diameter and opening position relative to the part references. Define the corner folds with their height, angle and extent. If those folds locate or contact another component, provide the mating geometry and the necessary clearance.
The listed equipment includes CNC bending and stamping machines. For an OEM quotation, send the latest drawing revision and quantity, together with any flatness or edge requirements. Mark whether a dimension refers to the unfolded profile or the finished plate so the manufacturing and inspection scope can be agreed.
