Custom Precision Stainless Steel CNC Machining | Laser Drilling and Broaching Three-Flange Body Enquiries

• CNC Machining or Not

  CNC Machining
  Type

  Broaching, Drilling, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, drilling, laser processing, milling, turning
• Material Capabilities

  Aluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel
  Micro Machining or Not

  Micro Machining
• Is it micro-machined?

  micromachining
  surface treatment

  Anodizing, polishing
• Material

  aluminum/alloy/zinc/brass/copper
  Drawing format

  2D/(PDF/CAD)3D(IGES/STEP)
• filler

  Poly bag + inner box + carton
  Delivery time

  7-15 Davs
• Minimum order quantity

  one item
  OEM/ODM

  Add
• equipment

  Three-axis, four-axis, and five-axis machining center

The T-shaped body has three flanged openings and raised cast markings. Treat it as a geometry reference; the markings do not independently certify alloy, pressure class or casting route.

Coordinate the three connection axes

Locate the main passage, branch opening and flange faces on the same drawing. Define the relationship of fixing holes to those references.

• Select the body drawing and material standard.
• Dimension the connected bore axes.
• Reference flange faces and fixing holes.
• Identify the specific broached or laser feature.
• Define gauges and final acceptance records.

Review machining access by feature

Specify actual stainless grade and blank condition before assigning drilling, laser work or broaching. Provide PDF/CAD or IGES/STEP data with stock allowances and finished limits.

Set component and duty acceptance

Agree compatible finish, quantities and dimensional inspection. Any pressure or sealing requirement needs its own evidence rather than inference from a cast mark or flanged shape.

Experience the power of custom precision manufacturing with our Stainless Steel CNC Machining services, featuring advanced laser drilling and broaching techniques. Our factory specializes in delivering high-quality components for industrial applications, utilizing state-of-the-art three-axis, four-axis, and five-axis machining centers for superior accuracy and consistency.

We offer a wide range of machining solutions including broaching, drilling, etching, laser machining, milling, and turning. Micro machining capabilities ensure we can handle even the most intricate requirements. Materials supported include stainless steel, aluminum, brass, bronze, copper, hardened metals, and precious metals for maximum versatility.

Surface treatments such as anodizing and polishing are available to enhance both durability and aesthetics. Drawings can be submitted in 2D PDF/CAD or 3D IGES/STEP formats to facilitate fast and efficient order processing. Packaging is secure with poly bags, inner boxes, and cartons, ensuring safe delivery.

We accommodate OEM and ODM requests with a minimum order quantity of one item and quick delivery times within 7 to 15 days. Trust our Chinese B2B factory for reliable, custom CNC machining parts tailored to your exact specifications.
