Custom OEM ODM Manhole Covers and Valve Bodies | Sand Casting Enquiries

• Model Number

  Zenithus-Casting
  Material

  Aluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals etc.
• Process

  Die casting, Sand casting, Investment casting, Lost foam casting etc.
  Heat treatment

  Quenching & tempering; solution & aging
• Surface treatment

  Powder coating, Zinc plating, Laser engraving, Sandblasting etc.
  Inspection

  Metallographic analysis, MT, UT, RT, 100% visual+100%gauge, CMM etc.
• OEM/ODM

  Accept
  Application

  Auto, Motorcycle, Energy, Medical device, Robotics etc.
• Drawing Format

  2D(PDF/CAD), 3D(IGES/STEP)
  Certification

  ISO9001:2015/IATF16949
• Standard

  ASTM, AISI, DIN, BS, JIS, NF, AS

Start a custom sand-casting enquiry by identifying whether the order is for a manhole cover, a valve body or separate components of both types. These names describe different design problems. A cover must match its supporting arrangement; a valve body needs defined passages and mating connections. Neither name establishes a load class, pressure rating or approved end use.

Give each component its own drawing

Provide the drawing revision, actual material grade and quantities for each item. For a cover, show the outline, seating dimensions, supporting frame and any locating or lifting details required by the design. Identify the assembly in which the cover will be installed and state the acceptance requirements associated with that location.

For a valve body, define the internal passages, port openings, mating faces and surfaces requiring machining. Include section views or an IGES/STEP model where the outside drawing cannot describe internal geometry. PDF/CAD dimensions can identify finished features and the references from which they will be inspected.

Agree the casting and finished supply scope

State whether sand casting is required and discuss its suitability for the selected metal and geometry. Separate the casting blank from later machining, surface treatment and assembly operations. A general catalogue list of metals and casting methods is a starting menu, not the specification of every individual component.

• Identify the cover or valve-body component and drawing revision.
• Specify the actual metal grade and requested quantities.
• Locate seating, port and other finished mating interfaces.
• Define required machining, treatment and supplied condition.
• Set component-specific inspection and acceptance requirements.

Use the duty to define acceptance

Where a cover has a load requirement, provide the relevant installation and assessment criteria. Where a valve body contains fluid, specify the medium and any pressure, temperature or leakage requirements. Agree the inspection records and evidence needed for the order. Generic certification labels do not establish current applicable approval, and delivery arrangements should be confirmed for the particular project.

Zenithus Casting offers professional custom manhole cover and valve body sand casting services for global B2B customers. As a leading OEM and ODM manufacturer from China, we specialize in producing high-quality casted parts using advanced technologies and strict quality control standards.

Our factory is ISO9001 and IATF16949 certified, ensuring every product meets international standards such as ASTM, AISI, DIN, BS, JIS, NF, and AS. We work with a wide range of materials including aluminum, brass, bronze, copper, hardened metals, and precious metals to provide solutions for diverse industrial needs.

We support versatile casting processes like die casting, sand casting, investment casting, and lost foam casting. Additional services include heat treatment, surface finishing such as powder coating, zinc plating, laser engraving, and sandblasting. Full inspection methods including metallographic analysis, MT, UT, RT, visual, gauge, and CMM are available to guarantee your required specifications.

Zenithus Casting serves industries like automotive, motorcycle, energy, medical devices, and robotics. We accept 2D (PDF/CAD) and 3D (IGES/STEP) drawings to deliver customized solutions. Choose our one-stop service for reliable quality, fast lead times, and flexible OEM or ODM support.
