Product description
Project & Delivery Requirements
-
Model NumberS2402 2407RDrawing Format2D/(PDF/CAD) / 3D(IGES/STEP/STP)
-
MaterialGalvanized Plate / Steel /Aluminum /Stainless Steel Sheet PlateFinishPainting/ Anodizing/ Powder Coating/Nickel Chrome Plating
-
ColorPanton Color and Ral Color SupportedCertificateISO9001/ROHS/IATF16949
-
ProcessSheet Metal Fabricating + CNC + Surface TreatmentLogoAccept Customized Logo
-
PackingPlastic Bag + Carton + Plywood Pallet
Curved slots around the center of a round plate
The illustrated plate has curved openings, small fixing holes and a cut-out center detail. Define these features from the plate center, with the required outer diameter, thickness and edge condition.
A spring function needs its own specification
The original title mentions a spring, but the photograph does not establish spring behavior or a working deflection. If the part must flex, specify the alloy, condition and required force or deflection criteria for review.
Provide quantities, finish and a revision-controlled drawing. Mark the dimensions to inspect at the slots, center and fixing holes. Treat any decorative cut-out or marking as a specified feature rather than evidence of a brand relationship or a tested mechanical function.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
