CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberDmetal-200389Surface treatmentSmooth
-
CertificationISO9001:2008MaterialAluminum Alloy
-
Surface finishAnodized/oxide etc /powder coatedSizeCustomized Size
-
Tolerance±0.1ToolingMade by ourself
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)
A transmission gear set must be defined by its mating geometry and assembly requirements. The Dmetal-200389 machining enquiry identifies aluminum alloy, customized dimensions and a smooth surface, with anodizing, oxide and powder coating options to discuss. PDF, CAD, IGES and STEP drawings can be used to define the required components.
Specify the gears as a mating assembly
Show which gears are supplied together, the locating features and the dimensions that determine their fit within the transmission. Include the relevant tooth geometry and the inspection requirements on the drawing rather than expecting them to be inferred from a product photograph. For Dmetal-200389, confirm the selected aluminum alloy and the actual machining operations before accepting a manufacturing proposal.
Confirm finishing and application acceptance
Identify the gear surfaces that require the selected finish and those whose final dimensions control the assembly. The tolerance entry has no stated unit, so provide explicit feature tolerances and measurement criteria with the drawing revision. An aviation enquiry also needs its own applicable material, traceability and approval requirements; this page does not establish flight suitability or a current aviation certification. Request the relevant documents and agree the supplied gear-set scope for the actual order.
