Custom Aluminum CNC Machining and Stainless Steel Turning Enquiries for Stepped Hollow Parts with Radial Holes
Generate QR code
Product description
Project & Delivery Requirements
-
CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberS240401Product namecustom cnc machined parts
-
Surface treatmentanodizing/powder coating/painting/polishing / chrome plating etcMaterialAluminum Alloy
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)MOQ100 pcs
-
Materials Avaliablealuminum/ stainsteel steel/ brass/ zincCertificationISO9001:2015
-
ProcessCnc Machining+deburrs +surface treatmentLogoAccept Custom Logo
-
Tolerance0.01mm
Hollow center and stepped outer profile
The example has an open axial bore, several outer diameter changes and a radial hole near the upper end. Define the bore depth and wall sections in a drawing, together with the positions and widths of the circumferential grooves. Hidden features need their own dimensions.
Model S240401 names aluminum alloy and includes stainless steel among available machining materials. Confirm the grade for each enquiry. CNC turning, milling, deburring and surface treatment are listed, with MOQ 100 pieces and PDF, CAD, IGES or STEP formats. Specify quantities, mating diameters and the required final surface condition before manufacture.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
