Product description
Project & Delivery Requirements
-
CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberDmetal-200389Surface treatmentSmooth
-
CertificationISO9001:2008MaterialAluminum Alloy
-
Surface finishAnodized/oxide etc /powder coatedSizeCustomized Size
-
Tolerance±0.1ToolingMade by ourself
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)
The retained block has openings on adjoining faces and a recessed feature on its top. Define the reference faces first, then dimension the holes and threads so their positions follow a common drawing system.
Material for the selected block
State the actual alloy and condition. Titanium, brass and stainless requests require separate review from the dedicated aluminum-alloy entry; the picture does not identify chemistry.
Provide quantities, finish and any edge or internal-bore requirements. Mark inspection dimensions for intersecting features and mounting contacts. The block shape does not establish a fluid-routing function, pressure rating or a particular standard size.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
