Custom SS304 Stainless Steel CNC Lathe Turning Parts | Threaded Ring Machining Enquiries
Generate QR code
Product description
Project & Delivery Requirements
-
CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberDmetal-200389Surface treatmentSmooth
-
CertificationISO9001:2008MaterialAluminum Alloy
-
Surface finishAnodized/oxide etc /powder coatedSizeCustomized Size
-
Tolerance±0.1ToolingMade by ourself
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)
Stepped round forms with central threaded openings
The two examples have broad circular faces, outer diameter steps and a central bore. Define the internal thread, end-face contacts and outside profile from a common axis.
Material specification for the ring
For SS304, state the actual material standard and required records. The dedicated aluminum-alloy field and general stainless capability list do not independently verify that grade for these examples.
Include quantities, finish and drawing revision, with inspection criteria for thread fit and concentric features. The image does not establish sealing performance, a standard ring size or one tolerance for every feature.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
