Custom Aluminum CNC Half Pin Parts | 1 1/4 Inch Anodized Marine Project Enquiries
Generate QR code
Product description
Project & Delivery Requirements
-
CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberDmetal-200389Surface treatmentSmooth
-
CertificationISO9001:2008MaterialAluminum Alloy
-
Surface finishAnodized/oxide etc /powder coatedSizeCustomized Size
-
Tolerance±0.1ToolingMade by ourself
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)
A single upright lug above a round mounting section
The example has a rounded lug with a transverse opening and stepped cylindrical regions below it. Define the pin-hole axis and mounting section together, including the mating component and installed clearances.
For a 1 1/4 inch marine project, identify which interface that nominal size describes and provide its actual dimensions. The general parameters do not verify a measured diameter or standard fit.
Finish and service requirements
Specify alloy, quantities and anodizing, with inspection criteria for the bore and mounting contacts. State required marine or load tests for the actual assembly; the image does not establish a working-load rating.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
