Custom Anodized Aluminum Female and Half Pin Components with CNC Turning for Marine Assembly Enquiries
Generate QR code
Product description
Project & Delivery Requirements
-
CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberDmetal-200389Surface treatmentSmooth
-
CertificationISO9001:2008MaterialAluminum Alloy
-
Surface finishAnodized/oxide etc /powder coatedSizeCustomized Size
-
Tolerance±0.1ToolingMade by ourself
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)
Eye end and cylindrical locating base
The main example has a rounded upper end with a transverse hole, a relieved side and a cylindrical lower section with a shoulder. Define the hole axis from the lower locating diameter and show the mating pin and clearances in the assembly drawing.
Model Dmetal-200389 lists aluminum alloy CNC turning, milling and drilling with customized size and anodizing options. Provide the alloy, quantities and PDF, CAD, IGES or STEP drawings. For a marine assembly enquiry, specify the actual service conditions, finish and inspection requirements. Agree the final fit after treatment; no nominal pin size, marine certification or load rating is established by the image.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
