Custom Aluminum Sheet Metal Bending and Stamping Fabrication for Ribbed Mounting Plates
-
Model NumberLZXMaterialsteel, stainless steel, aluminum, galvanized steel,
-
SizeCustomized sizeApplicationMachinery/Industry/Home/Automotive
-
ColorCustomized ColorProcessStamping
-
ServiceCustomized OEMUsagePrecision Metal Stamping Product
-
TypeOEM PartsEquipmentCNC Bending/Stamping Machine/Laser Marking
Ribbed plates with slotted end flanges
This custom sheet metal example shows a rectangular plate with three long raised ribs, folded ends and a combination of elongated slots and round holes. Its profile provides a clear starting point for discussing a formed mounting plate. The LZX listing offers customer-defined dimensions and names aluminum, steel, stainless steel and galvanized steel as material choices.
The rib shape and finished bend geometry are part of the component definition. A drawing should show rib length, height and spacing, along with the end-flange dimensions. Define the slot widths and positions relative to the plate references, so that mating fasteners and installation clearances can be checked.
From example geometry to an OEM drawing
Stamping and CNC bending are listed manufacturing capabilities. Confirm the operations needed for your chosen sheet and section, including any required edge finishing or surface treatment. The photograph does not establish a load rating or a tested stiffness value.
When requesting a quotation, provide the material designation, sheet thickness, drawing revision and quantity. Identify whether dimensions apply before or after forming, and flag the mounting features that must align with the surrounding assembly.
