Zamek Boczny 18X64-C Mining Side Lock with Arms Without Bevels

• Model Number

  S2311-2405
  Material

  Iron
• Application

  Mine/Auto/Industry/ Home
  Dimensions

  Customer Required
• Surface treatment

  Paint/Powder Coating/Oxidation etc
  Mold making

  By Ourselves
• Service

  OEM ODM
  Quality Control

  Professional Inspection
• Packing

  Individually Packed or as per your requirements
  Process

  Forging+Machining(if Need)+Surface Treatment

This mining side-lock enquiry uses the 18X64-C designation and an arms-without-bevels configuration. Match that description to the selected component drawing before agreeing the material, manufacturing operations and connection scope.

Make the arm configuration explicit

Show the arm profile and the surfaces intended to remain without bevels on the 18X64-C drawing. Identify the joining faces, contact areas and any locking elements that belong to the order. The configuration description should be checked against the actual mating arrangement rather than treated as a complete dimensioned specification.

Match the 18X64-C designation to the mating chain

Provide the meaning and units of the designation together with the mating-chain dimensions. Confirm the opening, engagement and clearances needed for the intended connection. An 18X64-C label does not by itself establish universal replacement fit, a particular dimensional standard or a rated load.

• Identify the 18X64-C side lock and the required arm profile.
• Dimension the no-bevel surfaces and joining interfaces explicitly.
• Provide the mating-chain geometry and the designation units.
• Specify the ferrous material grade and condition for the side lock.
• Define machining, finishing and service-acceptance requirements.

Agree the forged component and its acceptance

The manufacturing scope can include forging, machining where required and surface treatment. Identify which side-lock features need a finished dimension and how they will be accepted for assembly. Include the operating loads and any fatigue, mining or lifting qualification requirements so the selected connection can be assessed for its actual duty.

For an 18X64-C side lock with arms without bevels, a useful enquiry links the arm configuration and mating-chain drawing to the ordered material and required acceptance evidence. The component designation remains a starting point for that agreement, not a substitute for it.
