Custom Precision 3 4 Axis Aluminum CNC Milling Turning and Anodizing Parts with Stepped Bores
-
CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Rapid Prototyping, Turning, Wire EDM
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberS200448Product namecustom cnc machined parts
-
Surface treatmentSmoothCertificationISO9001:2008
-
MaterialAluminum AlloySurface finishAnodized/oxide etc /powder coated
-
SizeCustomized SizeToolingMade by ourself
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)MOQ100pcs
-
Materials Avaliablealuminum/ stainsteel steel/ brass/ zinc
Stepped openings and circular fitted features
The pictured selection includes a plate with stepped circular openings, a separate split ring and two rounded knob-like components. CNC milling and turning can be assessed for the required item, using the actual component drawing and assembly clearances.
For the plate, dimension the opening diameters, step depths and fixing-hole pattern. For a ring or rounded component, specify the bore, outer profile and required fit. Identify each ordered item separately, including the features relevant to 3 or 4 axis machining.
Color and finished dimensions
Model S200448 lists aluminum alloy with customized sizes and anodized, oxide or powder-coated finishes. Supply the color reference and any masking requirements around fitted openings. PDF, CAD, IGES and STEP formats are listed, with a minimum order of 100 pieces. Include quantities, drawing revisions and final inspection requirements for quotation.
