Custom ABS Plastic Injection Molding Parts | Hollow Connector Components

• Model Number

  S240306
  Plastic Modling Type

  Injection
• Processing Service

  Moulding, Cutting, Painting
  Certification

  ISO9001 CE
• Material

  PA66/PP/ABS /PC, Etc
  Feature

  High Precision Injection Parts
• Product name

  Plastic Injection Parts
  Drawing Format

  2D/(PDF/CAD)3D(IGES/STEP)
• Surface treatment

  Polish. Etched. Texture.electroplating.painting
  Color

  Customer's Request
• Process

  Injection Mould Plastic Part
  Application

  Industrial Plastic Parts
• Keyword

  Plastic injection

Define the connector-like component through its hollow cylindrical ends and wider angular body region. The three black examples show similar forms from different positions. Their appearance does not establish exact bore or thread dimensions, actual ABS formulation, a supplied set or suitability for electrical or pressure service.

Describe the internal passage and mating ends

Provide sections and actual connection requirements from the adjoining assembly. Locate cylindrical regions, collars and contact surfaces from functional datums. Specify whether ends require threads, plain fits or another connection, and identify any seals, inserts or hardware included in the delivered scope.

Select ABS and compatible surface processing

State the actual resin grade and required condition. Other listed polymers are separate material choices and need their own specifications. Define any polishing, texture, electroplating or painting only where compatible with the selected resin and component purpose, with appropriate appearance and masking requirements.

• Identify each hollow connector and drawing revision.
• Dimension bore, ends, collars and mating contacts.
• Select actual ABS grade and supplied condition.
• Specify compatible finish and included accessories.
• Agree connection checks and application evidence.

Accept the connector in its finished condition

Mark tolerances with units and measurement conditions at the working interfaces. Provide actual service conditions and applicable methods for any pressure, sealing, electrical or environmental requirement. A hollow form alone does not establish a functional rating or current qualification.

PDF/CAD or IGES/STEP geometry provides a listed starting point for the enquiry. Include quantities and required material or inspection records, and agree any additional documentation needed for the actual component.
