Custom Small CNC Machined Threaded Parts | Stainless Steel Brass Copper and Zamak Enquiries
-
CNC Machining or NotCnc MachiningTypeBroaching, DRILLING, Etching / Chemical Machining, Laser Machining, Milling, Other Machining Services, Turning, Wire EDM, Rapid Prototyping
-
Material CapabilitiesAluminum, Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel AlloysMicro Machining or NotMicro Machining
-
Model NumberS240307Product namecustom cnc machined parts
-
Surface treatmentanodizing/powder coating/painting/polishing / chrome plating etcMaterialAluminum Alloy
-
Drawing Format2D/(PDF/CAD)3D(IGES/STEP)MOQ10 pcs
-
Materials Avaliablealuminum/ stainsteel steel/ brass/ zincCertificationISO9001:2015
-
ProcessCnc Machining+deburrs +surface treatmentLogoAccept Custom Logo
-
Tolerance0.01mm
Internal and external threads on a compact body
The examples show short bodies with wide external threads and recessed internal openings; one view also has a hexagonal wrenching region. Define both thread specifications and the relationship between their axes, with the overall body and end-face dimensions.
For stainless steel, brass, copper or Zamak machining, specify the selected alloy rather than assigning every material option to the same fitting. The dedicated aluminum-alloy field does not identify the photographed material.
Functional interfaces for review
Include quantities, finish and the required thread and face inspection. State the mating components and any sealing or service requirements separately. The gold appearance and fitting shape do not establish alloy composition, pressure capacity or a specific plumbing application.
