Custom High Density Aluminum Heat Sink Extruded Profiles with Skived Fin Manufacturing Enquiries
Generate QR code
Product description
Project & Delivery Requirements
-
Grade6000 SeriesTemperT3-T8
-
ApplicationTransportation Tools, Industrial EquipmentShapeT - Profile
-
Alloy Or NotIs AlloyModel NumberDM2012
-
Tolerance±1%Processing ServiceBending, Decoiling, Welding, Punching, Cutting, extruding
-
Delivery Time22-30 daysProduct material6061 6063 Aluminum
-
ColorBlack MetalSizeCustomized
-
Surface treatmentAnodized/oxide etc /powder coatedToolingMade by ourself
-
PackingCartonProcessSand casting +CNC Machining
-
CertificationISO9001-2008MachiningAvailable
Dense fins between exposed mounting areas
The example has parallel fins on a rectangular base, with fixing holes in the exposed side areas. Define the hole pattern and contact-face geometry from common references, then dimension the fin height, thickness and spacing.
State the aluminum alloy and temper required for the project. If the design calls for extrusion or a skived-fin route, identify that manufacturing requirement explicitly along with the section length and any secondary machining.
Cooling conditions for review
Include the heat-source footprint, available airflow and mounting arrangement. Provide the thermal requirement, finish and quantities, with inspection dimensions for the base and fixing interfaces.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
