Product description
Project & Delivery Requirements
-
Grade6000 SeriesTemperT3-T8
-
ApplicationHeat SinkShapeAngle
-
Alloy Or NotIs AlloyModel NumberS 2410
-
Tolerance0.02mm, ±0.02Processing ServiceBending, Decoiling, Welding, Punching, Cutting, Machining
-
Delivery Time15 daysProduct nameCustom CNC Machining Aluminum Extrusion Profiles
-
Material6063/ 6061 etcMachiningAvailable
-
Surface treatmentAnodized/oxide etc /powder coatedToolingMade by ourself
-
Surface ColorCustomized Panton Colors
A central threaded bore supported within a hollow profile
The example has a curved outer shell, internal webs and a channel along one side. Dimension the bore axis and channel contacts together, including the section's wall thicknesses and the mating hardware geometry.
Specify the actual alloy and temper for the project. The material options name 6061 and 6063; a 6082 request needs separate review rather than being inferred from the general list.
Machining and finished fit
Include cut length, quantities and any holes or end processing, with the selected surface treatment. Mark thread and profile dimensions for inspection. Similar photographs elsewhere do not establish a separate section size, alloy or industrial load rating.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
