Custom Aluminum Extruded Heat Sink Enclosure Profiles with Internal Slots and Mounting Flanges
Generate QR code
Product description
Project & Delivery Requirements
-
Grade6000 SeriesTemperT3-T8
-
ApplicationHeat Sink, Industrial EquipmentShapeT - Profile
-
Alloy Or NotIs AlloyModel NumberDmetal-200329
-
Tolerance±1%Processing ServiceBending, Decoiling, Punching, Cutting
-
Delivery Time22-30 daysProduct material6061 6063 Aluminum
-
ColorBlack MetalSizeCustomized
-
Surface treatmentAnodized/oxide etc /powder coatedToolingMade by ourself
-
PackingCartonProcessSand casting +CNC Machining
-
CertificationISO9001-2008MachiningAvailable
Internal guides and external mounting flanges
The section example has a hollow center, internal guide features, external fins and feet extending along both sides. Dimension the internal guides from the base reference and show the mating component or panel that engages them.
For a custom extruded aluminum enclosure enquiry, specify the alloy and temper, full cross-section and cut length. Identify the interfaces to end closures and any holes or machined features needed after cutting.
Define the supply condition
State whether the enquiry covers the profile alone or additional enclosure components. Include the finish, mounting requirements, quantities and drawing revision, with any thermal or environmental requirements for the completed assembly.
Please include the drawing revision, material specification, quantity, critical dimensions, finish and inspection documents needed for your part. Tooling, samples, delivery and any return or remedy arrangements are subject to the agreed order terms.
