Model NumberS2306Plastic Modling TypeInjection
-
Processing ServiceMoulding, Cutting, PaintingColorCustomized
-
SizeCustomized SizeMaterialPA66/PP/ABS /PC, Etc
-
CertificationROHSFeatureHigh Precision
-
ShapeCustomized ShapesPackingStandard Carton Box
-
ServicePrompt DeliverySurface finishMatt Surface
-
PackagePP Bag
S2306 custom plastic injection molding can be discussed for the automotive component requirement defined in your drawing. The illustrated panel has a broad recessed area, a circular opening and several locating features. Size, shape and color are customized, with PA66, PP, ABS and PC material options and a matte surface finish.
Map the panel openings to the surrounding assembly
Provide the mating geometry for the S2306 panel, including the recessed area, openings and attachment locations. Mark the visible face and the dimensions that control alignment with adjacent trim or components. Identify the intended vehicle part and drawing revision so the manufacturing discussion refers to the actual assembly rather than a generic automotive application.
Review resin and appearance for the specified conditions
State the required resin grade, color reference and surface appearance, together with any operating conditions or material documentation required by the project. Cutting and painting can be included where the design calls for those operations. Confirm the finished dimensions and inspection points after the selected operation sequence has been agreed.
For an S2306 automotive enquiry, supply the quantity and applicable part-qualification requirements with the drawing package. Vehicle fitment, current approvals and any safety-related performance require configuration-specific evidence. The manufacturing proposal should identify the exact panel scope and acceptance documents before an order is approved.
